311 - torque converter, housing & case (unit) for Nissan Sunny California / Wingroad WFNY10

	Frame / Series WFNY10 / CY10 body W/4D (wagon 4-door ) engine GA15DE (1500 gasoline twincam EGI) drive 4WD (four-wheel drive ) Manufacture period 06.1995 - 05.1996 grade TYPE/B (type B) transmission AT.F4 (automatic transmission 4-speed )

---

Applies for models	Manufacture period	Spec
AT.F4	06.1995 - 05.1996	ｺﾝﾊﾞｰﾀｰﾊｳｼﾞﾝｸﾞ(RL4F03A)(ｻﾆｰ ｶﾘﾌｫﾙﾆｱ)

Open full screen picture Up to the top

0812061628 31100 - converter assembly, torque 31300 - housing assembly, converter 31301A - bolt 31301AA - bolt 31328 - tube, lubricant 31328E - clip 38342P - seal, oil differential converter housing

---

Applies for models	Manufacture period	Spec
AT.F4	06.1995 - 05.1996	ｹｰｽ (RL4F03A) (ｻﾆｰ ｶﾘﾌｫﾙﾆｱ)

Open full screen picture Up to the top

28365Y - terminal, earth 31301J - clip 31310 - case assembly, automatic transmission 31310D - pin, dowel 31319Q - plug, thread 31319QA - plug, thread 31379M - seal, oil 31381 - breather, air 31390 - pan assembly, oil 31390A - bolt 31390AA - bolt 31390AB - bolt 31390J - magnet 31391 - cover, side transmission case 31394 - plug, drain 31394E - washer, drain plug 31397 - gasket, oil pan 31397M - gasket, side cover 31526Q - seal,O ring 31526QA - seal,O ring 31981 - support, parking actuator 31981D - bolt 31986 - shaft, parking pole 31988 - spring, return pole 31991 - pole, parking 38342Q - seal, oil differential transmission case C1335 - sealant, fluid

Sunny California / Wingroad WFNY10
